Product Specifications
| Depth Resolution | 640*400 |
| Depth Working Distance | 0.3-1.2m |
| Depth Precision | ＜0.6% |
| Depth Accuracy | ＜0.75% |
| IR FOV | 45.7°(H)*68.2°(V) |
| IR Resolution | 1280*800@30fps |
| IR Wavelength | 940nm |
| RGB FOV | 61.4°(H)*76.6°(V) |
| RGB Resolution | 3264*2448@30fps |
| RGB HDR | YES |
| RGB Output Interface | MIPI |
| Working Temperature | -5~40℃ |
| Power Consumption | 660mW |
| Dimensions | 62*13.5*6.9mm |
Product Applications
Facial Recognition
Product Features
Miniaturized Structured Light Facial Recognition
Utilizes structured light facial recognition technology, achieving fast and stable identification via a MIPI interface.
Miniaturized structured light module saves space and is easy to integrate, suitable for various smart retail scenarios and terminals.
Analyzes depth images, IR data, and RGB data to perform liveness detection and assess image quality to determine suitability for cloud recognition.
Screens facial images to exclude those with insufficient expression, partial occlusion, and blurriness, ensuring only high-quality images are processed.
