Mars01H-Wide FOV Obstacle Avoidance

Mars01H

The Mars01H features a 120° field of view and is equipped with a high-performance computing platform. It incorporates depth perception algorithms developed by Sunny Intelligent Optics. The terminal can obtain high-precision 3D depth information via a USB 2.0 interface, facilitating backend processing.

WeChat ID: shunyuzng

Home / Products/ToF Camera/Mars01H

Product Specifications

FOV	120°(H)*56°(V)
Frame rate	10fps & 15fps
Accuracy	0.05-0.4m ≤5c m0.4-2.5m≤1% of distance
Working distance	0.05-2.5m

LED Operating Wavelength	850nm (VCSEL)
Supported Systems	Linux, Windows, ROS, Android
Power Supply Interface	USB 2.0
Dimensions	442521.4 mm

Product Applications

SLAM

Navigation and Positioning

Identity Detection

Multi-Directional Autonomous Obstacle Avoidance

Product Features

Plug-and-Play, Secure and Reliable

Small size and low power consumption, easy to integrate.

Integrated embedded depth perception algorithm platform, easy to call from the backend.

Laser Class I safety certification, ensuring eye protection.

UVC protocol, driver-free plug-and-play.

Sunny Optical has deployed technologies and products based on the two application areas of identification and positioning. The scenario applications cover XR and smart wearables, robots, AIoT (smart home, smart business, smart logistics, etc.). Welcome to contact us, you can add WeChat ID: shunyuzng.
