Product Specifications
| Dimensions | 69.2*18*26mm |
| Output Interface | TReinforced USB 2.0 wafer |
| Operating Voltage | 5V |
| Operating Distance | 0.3-2m |
| Operating Temperature | -10℃~50℃ |
| Operating Humidity | ＜95% |
| Power Consumption | ＜1.9W |
| Laser Safety | Class Ⅰ, IEC60825-1:2007 Ed 2, IEC60825-1:2014 Ed 3 |
| RGB | FOV | 58°(H)*73(V) |
| Resolution | 480*640@ 10 fps | |
| Format | YUV420p | |
| Auto Exposure | YES | |
| Depth | FOV | 58°(H)*73(V) |
| Resolution | 480*640@ 10fps | |
| Format | Raw 16 bit | |
| Depth Accuracy | ＜1% |
Product Applications
Robot Obstacle Avoidance
Face Recognition and Liveness Detection
Volume Measurement
Financial Payment
Product Features
Built-in Algorithms, High-Precision Obstacle Avoidance
Suitable for service robot intelligent obstacle avoidance and AI recognition.
HDR RGB-D registered video output and high-precision depth map output.
Built-in warning line detection algorithm to save main controller computational power.
Built-in HDR, resistant to strong outdoor light interference, suitable for a wide range of usage environments.
Supports 3D coordinate transformation and simulated 2D radar format output.
Contact Us
Sunny Optical has deployed technologies and products based on the two application areas of identification and positioning. The scenario applications cover XR and smart wearables, robots, AIoT (smart home, smart business, smart logistics, etc.). Welcome to contact us, you can add WeChat ID: shunyuzng.
