Product Specifications
| Operating Temperature | -10~60℃ (Operating Temperature Range for the Entire Unit) |
| Supported Systems | Linux Ubuntu 14.04/16.04, Windows X86/X64 |
| UVC Protocol | YES |
| IP Rating | IP67 |
| Output Interface | USB 2.0 |
| Dimensions | 95*38.5*35.5 (mm) |
| RGB | FOV | 148°(H)*126°(V) |
| Resolution | 1280*1080 @10fps (Croppable) | |
| Pixel Dimension | 2.7μm*2.7μm | |
| Resolution After Depth Registration | 720p (Croppable) | |
| Exposure Method | 全局曝光 | |
| Depth | FOV | 120°(H)* 56°(V) |
| Resolution | 224*109 @10 fps | |
| Working Distance | 0.1-2.5m @ 90% Reflectivity | |
| Accuracy | 1.5cm @0.1-0.5 ≤1.5% @0.5-2.5m | |
| Projector Wavelength | 红外 940nm |
Product Applications
Lawn Mower Robot Obstacle Avoidance
Product Features
Precise Obstacle Avoidance: Achieves accurate visual perception in complex outdoor environments.
Achieves high-precision depth information collection, providing stable obstacle avoidance support for lawn mower robots around the clock.
Designed specifically for outdoor use, featuring fenceless intelligent boundary recognition that is unaffected by changes in external environmental lighting.
Supports customized form factor development, offering personalized visual module solutions.
Multi-terrain obstacle recognition and avoidance, including but not limited to shrubs, trees, rocks, terrain undulations, and potential potholes or depressions; maintains stable obstacle avoidance performance even when operating on slopes, inclines, or declines.
