Product Specifications
| Resolution | 1920*1080 |
| Frame Rate | 1080P@30fps |
| FOV | 91.1°(D)*82°(H)*51.4°(V) |
| Lens Focal Length | 3.14mm |
| F.NO | 2.2 |
| Output Format | MJPEG |
| Dimensions | 20*50*11.02(mm) |
| Power Consumption | ≤1W |
| Working Temperature | -10℃~50℃ |
| Storage Temperature | -30℃~80℃ |
| Dynamic Range | ≥12bit |
| SNR | ≥40db |
Product Applications
Smart home
Product Features
High Definition Image Quality and Wide Dynamic Range
Supports 1080P@30fps high-definition resolution, delivering clear and detailed video images.
True-to-life RGB color reproduction ensures accurate image colors.
Supports wide dynamic range and automatic exposure (AE), adapting to various lighting conditions while maintaining clear images.
Supports MJPEG output in multiple resolution formats, flexibly meeting the needs of various application scenarios such as video surveillance and smart home systems.
One-Click Upgrade, Convenient Experience
Designed based on the UVC protocol, it achieves plug-and-play functionality via a USB 2.0 interface.
Supports one-click firmware upgrades using Windows tools.
