Product Specifications
| Resolution | 1920*1080 |
| Frame Rate | 1080P@30fps |
| FoV | 178.4°(D)*150.2°(H)*80.4°(V) |
| Lens Focal Length | 2.28mm |
| F.NO | 2.2 |
| DOF | 0.2-16.8m |
| Working Temperature | -10℃-50℃ |
| Storage Temperature | -30℃-80℃ |
| Output Interface | USB |
| Output Format | H.264\MJPEG |
| Dimensions | 45*25*18.2mm |
| Power Consumption | ≤0.925W |
Product Applications
Smart home
Product Features
High Definition Image Quality and Wide Dynamic Range
Supports 1080P@30fps high-definition resolution, delivering clear and detailed video images.
Features automatic exposure (AE) to adapt to various lighting conditions, maintaining clear images.
Supports MJPEG output in multiple resolution formats, providing flexible solutions for video surveillance, smart home systems, and other applications.
Designed based on the UVC protocol, it achieves plug-and-play functionality via a USB2.0 interface.
